Dimensions |
86mm * 86mm * 38mm |
|
Material |
PC + Armored Glass |
|
Weight |
100g |
|
Voltage |
DC 12V (5V – 30V), USB 5V |
|
Current |
<160mA 12V power supply |
|
Communication Port |
Wiegand, RS232, RS485, USB |
|
Image Sensor |
640 x 480 CMOS, 30fps |
|
Perspective |
Horizontal 63’, Vertical 51’ |
|
Reading Angle |
Roll: 360’, Pitch: ± 60’, Skew: ± 50’ |
|
Reading Code System |
On by default: EAN13, EAN8, UPC-A, UPC-EO, UPC-E1, Code 128, Code 39, Code 93, CodaBar, QR Code, PDF417, DataMatrix Off by default, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code 11, MSI Plessey, RSS-14, RSS-Limited, RSS-Expanded |
|
Reading Distance |
0 – 200mm (6-inch mobile phone, WeChat QR payment code) |
|
Reading Accuracy |
1D: ≥ 5mil / 2D: ≥ 10mil |
|
Symbol Contrast |
≥ 25% |
|
Recognition Pattern |
Active / passive, with support for induction mode |
|
Sweep Code Feedback |
Beeping: the green light indicates scanning code |
|
Card Swipe Support |
ISO14443A / B, support ID card physical ID, NFC mobile phone card |
|
Operating Temperature |
-20°C ~ 60°C |
|
Operating Humidity |
5%RH~95%RH (Non-Condensing) |
|
Storage Temperature |
-40°C ~ 80°C |
|
Ambient Lighting |
0-80000Lux |
|
Electrostatic Protection |
Contact discharge ± 6KV and air discharge ± 12KV |
|
IP Protection |
Front IP54 |
